Product Details:
Payment & Shipping Terms:
|
| Brand Name: | Favorable | Product Name: | Favorable High-effient SPX5 Automatic Spreader Machine |
|---|---|---|---|
| Applicable Industries: | Garment,Luggage,Automotive Interior,Advertising,Furniture And Packing | Usage: | Textile And Garment Manufacturing |
| Strength: | Servo Motor Control, High Positioning Accuracy | Fabric Spreading Width: | 160/190/210/260/310cm |
| Package: | Standard Export Package With Ply Wood | Warranty: | 1 Year |
| High Light: | SPX5 Automatic Spreader Machine,SPX5 Spreader Machine,Continuously Automatic Spreader Machine |
||
Favorable High-effient SPX5 Automatic Spreader Machine
Favorable SPX5 Automatic Spreader Machine – High-effiency, accuracy and cost-effective choice
Super Configuration:
1. Servo motor control, positioning accuracy up to micron level;
2. Microcomputer automatically calculate, photoelectric sensor feeding cloth;
3. Humanized design with device spread fabric easy to have curled edge;
4. PLC control system assisted with photoelectric sensor, sensitivity adjustable, one worker can operate;
Main Paramenters:
| Model | SPX5-160 | SPX5-190 | SPX5-210 | SPX5-260 | SPX5-310 |
| Spread Width | 1600mm | 1900mm | 2100mm | 2600mm | 3100mm |
| Maximum fabric weight | 80kg | 110kg | |||
| Maximum roll diameter | 450mm | 450mm | |||
| Maximum driving speed | 88m/min | 85m/min | |||
| Single pull maximum height | 220mm | 220mm | |||
| Double pull maximum height | 160mm | 160mm | |||
| Power | 1.2KW | 1.55KW | |||
| Power requirement | Single phase AC 220V 50Hz 15A | ||||
| Size: length, width, height | 230x165x95cm | 260x165x95cm | 280x165x95cm | 330x165x95cm | 380x165x95cm |
| Machine weight | 400kg | 415kg | 425kg | 475kg | 510kg |
| Panel width | 1835mm | 2135mm | 2335mm | 2835mm | 3335mm |
Other recommended products: Favorable Ultra-high speed Inkjet plotter
Main Paramenters:
| Model | LH200-2 2 Heads | LH220-2 2 Heads | LH240-2 2 Heads | LH240-4 4 Heads |
| Printing Density | 600dpi Draft mode:300dpi (Save-ink Mode Is Optional) | |||
| Scanning Speed | (135Sqm/Hr) 300 〜600DPI |
(135Sqm/Hr) 300 〜600DPI |
(135Sqm/Hr) 300 〜600DPI |
(240Sqm/Hr) 300 〜600DPI |
| Max. Width Of Paper | 173cm | 198cm | 235cm | 235cm |
| Max. Plotting & Cutting Width | 165cm | 185cm | 205cm | 185cm |
| Line Quality | Works Precisely, Smoothly, And No Gap Between Two Contiguous Sections. | |||
| Software Compatibility | HPGL (Special Format Can Be Back-ordered) | |||
| Paper Feed System | Accurate Tracking System And Inside Digital Sense System Insure Marker Paper Is Feed Continually And Accurately More Than 3000m Long. | |||
| Paper Installation Mode | Front Or Back Paper-supply System Is Optional. | |||
| PaperTake-up Mode | Take-upautomatically or manually, Can plot many a mass of short marker, and save a lot of time for taking-up paper. On automatic taking-up method, it can work for overnight printing. | |||
Company information:
Favorable Group suceed as professional cutting system solution provider, dedicated to providing auto-cutter/spreader/plotter machine, parts and maintanence service over two decades.
Our core value build by our team, which found by a group of technician, we start business to offer spare parts and maintanence service for cutting system(cutter, plotter, spreader) since 2005. Thus we deeply study on machine performance, technique and different solution, to analysize the difference from then and how to integrate their strength and avoid their shortage, well knowing how to mainten the machine efficiently and control the maintence cost.
To respond the trend of various demands on the market and the trust of our long-term cooperated customer, we started developing machine from 2015, aim at provide better solution on machine cost, plotting tech and efficiency.
With continuous technical support from our strategic partners in US/ Japan /Singapore and UK, now we have successfully developed machine
series include:
1.Inkjet plotter; Inkjet cutting plotter; AIS Wide Scan Recorder
2.Spreader
3. Single-ply cutter; Multi-ply cutter
Achieve an annual production capacity of 6,000 sets equipment.
Below more machines for your reference:
Favorable Ligthning Engine Series Inkjet Cutting Plotter
You are welcome to visit our company and factory in Dongguan City,Guangdong Province China, would be honor to guide you a tour to review our operations for raw material, customized spare parts, production, storage services, and sewing services, and drop ship to the end customer, all these services are offered at excellent prices.
You have our commitment of high quality services, quick response and fast lead time with the most reasonable prices. Patient and professional sales team, technicians will support you from start to the end. All our aim is too deepen our cooperation, and work further for higher goals in the future with our valued customer.
